Details
-
127 SLIDING DOOR SERIES
PATIO HEAVY-DUTY THERMAL BREAK SLIDING DOOR- Profile thickness
- Frame depth : 127mm / Visiable Width : 50mm
- Profile thickness : Frame 2.2mm / Sash 2.2mm
- Specification
- Sash Wide Range: 700mm-3300mm
- Sash Height Range: 1795-3300mm
- Heavy-duty sliding door Slim middle frame design Optimized design for Patio Optional lift-sliding design Optional magnetic levitation auto door
- Thermal Break Material
- Insulation Strip: PA66+GF25 high-quality Nylon insulation strip
- Frame : 36mm
- Sash : 26mm
- Gasket Strip: High-performance EPDM foam composite sealing strip,standard soft and hard composite co-extruded isobaric rubber strip
- Mesh Fan
- Default: No fly-screen
- Glass
- Default Configuration:
- 6mm Double Silver LOW-E + 20Ar+ 6mm DGU Planitherm Toughened
- More optional glazing informaton please contact us
- Open means
- Sliding
- Basic param eters
HARDWARE PARTS
OPTIONAL COLOR
- #ff4713
- #c44f46
- #454b4b
- #4b4545
- #6f5e56
- #503d2e
- #423928
- #375146
- #8c8d88
- #423928
